Features

cc



Easy

The tapered design provides efficient locating. The movable tapered receiver bushings allow precise dual contact with easy processing of mounting holes.

Space-Saving

The compact tapered pins and tapered receiver bushings reduce wasted space.

Excellent Repeatability

Provides the locating repeatability at 10┬Ám or less with low cost.

5-Axis Modular Clamping Screws (CP156)

Used with CP150 series double clamping modules.

5-Axis Modular Diamond Taper Clamping Screw (CP155-D)

Used to locate a workpiece or clamping module in conjunction with CP155-L round-type screws.

5-Axis Modular Double Clamp Modules (CP151)

Used with CP155 and CP156 clamping screws.

5-Axis Modular Double Clamping Pin (CP158)

Used to couple clamping modules CP150, CP151 or CP152.

5-Axis Modular Flanged Clamp Modules (CP150)

Used with CP155 clamping screws.

5-Axis Modular Precision Locating Bushing (CP159)

Used with CP152 modular clamps on a base plate.

5-Axis Modular Precision Tapered Bushing (CP157-L)

Used to locate CP150 flanged clamping modules on a base plate.

5-Axis Modular Round Taper Clamping Screw (CP155-L)

Used to locate a workpiece or clamping module in conjunction with CP155-D diamond-type screws.

5-Axis Modular Single Clamp Modules (CP152)

Used to locate and clamp a workpiece in conjunction with CP155 clamping screws.

5-Axis Modular Standard Tapered Bushing (CP157-S)

Used to locate CP150 flanged clamping modules on a base plate.

Adjustable Torque Wrench (CP-TCW)

With or with socket.

Air Flex Light Locators (AMWF)

Port or Direct type pneumatic pin.

Air Flex Light Receivers (AMWF-BU)

Used with AMWF-L-S series pneumatic locator pin.

Air Flex Locators (AMWF-W)

Straight or tapered pneumatic pin.

Air Flex Receivers (AMWF-BU)

Used with AMWF-W series pneumatic locator pin.

Blind Style Locators (CP720)

Flex locator system.

Blind Style Protective Covers (CP725)

Flex locator system. Used keep out dirt and contaminants out of blind-style receivers.

Blind Style Receivers (CP725)

Flex locator system. Steel body.

Bolt-in Receivers (MPAR)

SpeedLoc system receiver.

Cam Handle Style Locators (CP731)

Flex locator system. Tapered or straight.

Docking Hardware (MP-DH)

SpeedLoc system docking plate and positioning stud.

Extendable Work Locators (CP701)

Die cast zinc handle, steel body.

Flush Mount Locators (MPAS)

SpeedLoc system locator.

Handle Style Locators (CP722)

Flex locator system. Tapered or straight.

Hex Style Locators (CP730)

Flex locator system. Tapered or straight.

Hex/Cam Style Receivers (CP735)

Flex locator system. Tapered or straight.

Knob Style Locators (CP723)

Flex locator system. Stainless knob and pin, steel body.

Locating Pins with Ball & Shoulder (03108)

Diamond or round. Steel or stainless steel.

Locating Pins with Ball without Shoulder (03107)

Diamond or round. Steel or stainless steel.

Low Profile Locating Pins

Round or diamond.

Protective Covers - Hex/Cam Style (CP735)

Flex locator system. Aluminum.

Spring Loaded Locators (CP710)

Standard or accurate type.

Standard Bushings (MPAL)

SpeedLoc system. Steel.

Standard Locators (MPAS)

SpeedLoc system locator.

Stepped Bushings (MPAL)

SpeedLoc system. Steel.

Thread-in Receivers (MPAR)

SpeedLoc system receiver.

Through Style Locators (CP721)

Flex locator system. Steel body.

Through Style Protective Covers (CP726)

Flex locator system. Used keep out dirt and contaminants out of through-style receivers.

Through Style Receivers (CP726)

Flex locator system. Steel body.
