Adjustable Clamp Handles & Levers

Clamp handles provide quick fastening and unfastening where space is tight.

Adjustable Clamp Handles & Levers



Adjustable handles and levers are commonly used in instances where fastening, unfastening, and adjusting become difficult due to space constraints. Pulling up on the handle disengages it from the spline and allows it to rotate 360 degrees in either direction. Releasing the handle re-engages the spline for tightening or adjusting. Torque limiting handles and knobs that prevent overtightening are also available, as well as quick-change cam levers. Our line of durable handles and levers are offered in several materials including steel, zinc, stainless steel and plastic. Male and female thread options as well as several color choices are also available.

BENEFITS



no tools

NO TOOLS

No tools needed to fasten.

ergonomic

ERGONOMIC

Convenient, easy to use - especially with space constraints.

oem

OEM

Ideal for use in manufacturing as well as on end products.

quality

QUALITY

High quality materials and construction.

Types



Adjustable Handles

Adjustable Handles



Available in a variety of colors and styles. Pulling up on the handle disengages it from the spline and allows it to rotate freely for adjustment. Releasing the handle engages it for tightening or adjusting.



View Products

Adjustable Tension Levers

Adjustable Tension Levers



Designed for use in tight spaces. Pulling up on the handle disengages it from the spline and allows it to rotate freely for adjustment. Releasing the handle engages it for tightening or adjusting.



View Products

Cam Levers

Cam Levers



Quick fastening and unfastening without the use of tools. They are ideal for quick change operations where parts only have to be loosened and not completely unassembled.



View Products



Torque Limiting Handles

Torque Limiting Handles



Designed to be used with a number of our standard One-Touch swing clamps as well as for use on custom clamping applications where overtightening must be prevented.



View Products

Torque Limiting Knobs

Torque Limiting Knobs



When the knob clicks into place, the user is assured of proper tightening torque every time.



View Products



Features



Lift to Engage

LIFT TO ENGAGE

Pulling up on the adjustable handle disengages it from the spline and allows it to rotate 360 degrees in either direction. Releasing the handle re-engages the spline for tightening or adjusting.







Line up

Adjustable Clamp Levers (06440)

Steel or stainless steel body. Stud or internal thread.

Aluminum Cam Handles (04232)

Steel or stainless steel stud/insert.

Angled Adjustable Tension Levers (06370)

Steel or stainless steel body. Stud or internal thread.

Flat Adjustable Tension Levers (06370)

Steel or stainless steel body. Stud or internal thread.

Low Profile Angled Adjustable Tension Levers (06390)

Steel body with stud or internal thread.

Low Profile Flat Adjustable Tension Levers (06390)

Steel body with stud or internal thread.

Plastic Adjustable Clamp Handles

Steel or stainless steel stud/insert. Variety of handle colors available.

Plastic Cam Handles (04232)

Steel or stainless steel stud/insert.

Plastic Cam Handles, Expansion (0118)

Adjust expansion of spring with nut to control clamping force.

Plastic Cam Handles, Quick Lock (04234)

As lever is pushed downward, the pin is drawn up for secure fastening.

Soft Touch Adjustable Clamp Handles (0252)

Steel or brass insert, or steel stud.

Stainless Steel Cam Handles (04232)

Stud or internal thread.

Steel Cam Handles, Low Profile (QLCA)

Black oxide or nickel plated finish.

Torque Handles (ATCL)

Stud or internal thread.

Zinc Adjustable Clamp Handles

Steel or stainless steel stud/insert. Variety of handle colors available.

Zinc Adjustable Clamp Handles, Straight Handle

Steel or stainless steel stud/insert.

Zinc Adjustable Clamp Levers (06410)

Steel or stainless steel stud/insert. Black or metallic finish.
